Car Speedometer

A car mounted speed and distance tool




Project goals

Create a distance measurement and speed reporting tool with TX in the car and a standalone RX unit. Units use BLE (Bluetooth low energy) to communicate.

  • 33 or 36“ wheel support
  • Standalone RX unit
  • Hall effect sensor and magnet mount on any car without much real wiring
  • 3D printed case for display-RX unit
  • Custom PCB for RX unit in boxcar
  • Deep sleep on TX and RX units for longer batery life
  • Technically, TX unit can be used to collect distance data and read by the RX unit after the fact

Build Log

11/1/2026 - Software is functioning with TX unit and simulated speed ramp. Waiting for Hall effect sensors to arrive.

11/3/2026 - Hall effect sensors arrived from Digikey.

11/10/2026 - Breakout boards for SOT23 package arrived.
